Advance ICN2TTP40SC35M 2-Lamp 40W CFL Ballast 120–277V Instant Start SC Case

Product Overview

The Advance ICN2TTP40SC35M electronic ballast is designed to operate two 40W 4-pin compact fluorescent lamps (FT40W/2G11) on a 120–277V input. It uses instant start operation to support quick lamp ignition and consistent performance in commercial lighting applications.

Key Features & Design

• Functionality: Electronic ballast designed to regulate current for 2-lamp 40W 4-pin CFL lamps, ensuring consistent lamp operation.
• Installation context:  Suitable for integration into compatible compact fluorescent fixtures, supporting retrofit and replacement applications.
• Notable specifications: Supports 2-lamp 40W CFL lamps (FT40W/2G11), 120–277V input, instant start, ballast factor 0.88 (nominal), power factor 0.98 (nominal), ~97–99W input power, automatic restart.
• Contractor-relevant details: Compatible with remote, tandem, and through wiring configurations, supporting reliable performance in commercial lighting systems.

Performance / Benefits

Instant start operation enables quick lamp ignition, while stable output supports consistent performance across a 120–277V input range. Its compatibility with multiple wiring configurations enables flexible installation in retrofit and maintenance applications.
