SensorWorx SWX-874-ELV-WH Wireless Phase Dimming Load Controller

Product Overview

The SensorWorx SWX-874-ELV-WH is a wireless phase dimming load controller designed for electronic low-voltage (ELV) and dimmable lighting loads. Operating at 120VAC single phase with a 20A load rating, this line-voltage controller enables wireless lighting control for commercial dimming applications supporting wireless lighting control in commercial dimming applications.

Key Features & Design

• Functionality: Wireless phase dimming load controller supporting reverse phase dimming for ELV, LED, CFL, incandescent, and halogen lighting loads, with optional forward phase operation.
• Installation context: Designed for single-gang wall box installation in commercial lighting control applications requiring wireless dimming functionality.
• Notable specifications: 120VAC single-phase operation; 20A load controller; reverse phase dimming (default); optional forward phase mode; wireless communication at 915 MHz; compatible with ELV, LED, CFL, incandescent, and halogen loads; less than 1-inch wallbox depth; UL listed.
• Contractor-relevant details: Wireless linking supports integration with compatible SensorWorx sensors and remote dimming stations while reducing low-voltage control wiring requirements.

Performance / Benefits

In commercial lighting applications, the SWX-874-ELV-WH provides reliable wireless dimming control for compatible ELV and LED lighting loads. Its shallow wallbox depth simplifies installation in crowded electrical boxes, while wireless pairing supports flexible lighting control layouts and future system adjustments.
