Advance ICN-4P32-N 4-Lamp T8 Electronic Ballast 120-277V

Product Overview

The Advance ICN-4P32-N is an electronic instant-start ballast designed to operate up to four F32T8 fluorescent lamps. Featuring universal 120–277V input and parallel lamp operation, it delivers reliable performance for commercial fluorescent lighting systems.

Key Features & Design

• Functionality: Operates up to four F32T8 fluorescent lamps using electronic instant-start technology with parallel lamp operation and independent lamp operation (ILO) capability.
• Installation context: Designed for commercial fluorescent lighting fixtures requiring a universal-voltage electronic ballast for T8 lamp systems. Compatible with 120–277V, 50/60Hz electrical systems.
• Notable specifications: Input Voltage: 120–277V; Ballast Type: Electronic; Starting Method: Instant Start; Lamp Connection: Parallel; Supports up to four F32T8 lamps; Power Factor: Up to 0.99; THD: ≤10%; Certifications: UL Listed.
• Contractor-relevant details: Universal-voltage operation simplifies replacement and retrofit projects across multiple building power systems. Independent lamp operation allows remaining lamps to continue operating if one lamp fails, reducing maintenance disruptions.

Performance / Benefits

The ICN-4P32-N provides reliable operation for T8 fluorescent lighting systems while supporting energy-efficient performance through high power factor and low harmonic distortion. Its instant-start design enables dependable lamp starting and consistent light output in commercial lighting environments.
