Westgate LF4MAX-MD-45-80W-MCTPB-KN-P-WH Medium LED Flood Light 45-80W Selectable CCT - White

Product Overview

The Westgate LF4MAX-MD-45-80W-MCTPB-KN-P-WH is a white round-back LED flood light designed for configurable outdoor commercial lighting. Selectable 45W, 60W, or 80W output and 3000K, 4000K, or 5000K color temperature provide flexible performance for a range of site lighting applications. The fixture operates on 120-277V AC and includes a photocell for automatic lighting control.

Key Features & Design

• Functionality: Selectable 45W/60W/80W output with 3000K/4000K/5000K CCT, 0-10V dimming, adjustable beam angle, and included photocell with disconnect switch.
• Installation context: Designed for general site lighting, alleys, loading docks, doorways, pathways, and parking areas. It can also replace existing HID flood lights and wall packs.
• Notable specifications: 120-277V AC, 50/60Hz; 6,300/8,400/11,200 lumens; 140 LPW; CRI ≥70; IP65; 70,000-hour rated life.
• Contractor-relevant details: Features a 90° adjustable 1/2-inch knuckle mount, die-cast aluminum housing with powder-coat finish, 6kV surge protection, 1.5-ft SJTW 18/3 AWG cable, wet-location suitability, and a 7-year warranty.

Performance / Benefits

Selectable wattage, CCT, and beam angle allow contractors to configure one fixture for multiple outdoor lighting requirements. The fixture delivers 6,300 lumens at 45W, 8,400 lumens at 60W, and 11,200 lumens at 80W, while 0-10V dimming and photocell control provide additional flexibility for commercial installations.
